Alkaline Button Cell

Alkaline button battery is a small primary battery, ‌ the positive electrode uses manganese dioxide, ‌ the negative electrode uses zinc, ‌ electrolyte uses alkaline aqueous solution. ‌ For its high cost performance and superior performance, ‌ is widely used in various small electronic equipment, such as ‌ toys, ‌ medical equipment and so on. ‌

Product Details

KINGCELL brand: KINGCELL品牌

Produced by HUATAI: 华太制造

Dry battery: 干电池

Alkaline Button Cell : 碱性纽扣电池

AG0/L521: AG1/L621

AG2/L726: AG3/L736

Item No	System	Voltage	Capacity	Dimension	Weight
AG0/L521	0%Hg Alkaline	1.50V	9mAh	5.8x2.1mm	0.23g
AG1/L621	0%Hg Alkaline	1.50V	12mAh	6.8x2.1mm	0.29g
AG2/L726	0%Hg Alkaline	1.50V	23mAh	7.9x2.6mm	0.44g
AG3/L736	0%Hg Alkaline	1.50V	40mAh	7.9x3.6mm	0.61g
AG4/L626	0%Hg Alkaline	1.50V	18mAh	6.8x2.6mm	0.34g
AG5/L754	0%Hg Alkaline	1.50V	66mAh	7.9x5.4mm	0.95g
AG6/L921	0%Hg Alkaline	1.50V	29mAh	9.5x2.1mm	0.55g
AG7/L926	0%Hg Alkaline	1.50V	38mAh	9.5x2.6mm	0.64g
AG8/L1121	0%Hg Alkaline	1.50V	40mAh	11.6x2.1mm	0.79g
AG9/L936	0%Hg Alkaline	1.50V	60mAh	9.5x3.6mm	0.88g
AG10/L1131	0%Hg Alkaline	1.50V	83mAh	11.6x3.1mm	1.11g
AG11/L721	0%Hg Alkaline	1.50V	17mAh	7.9x2.1mm	0.37g
AG12/L1142	0%Hg Alkaline	1.50V	100mAh	11.6x4.2mm	1.48g
AG13/L1154	0%Hg Alkaline	1.50V	170mAh	11.6x5.4mm	1.95g
